The Davies Craig 11-inch (28 cm) Thermatic® Brushless Cooling Fan (12V) is a premium solution for radiator, air conditioner condenser, and oil cooler applications. The brushless motor provides enhanced durability and efficiency, while the IP68-rated housing ensures reliable performance in harsh conditions.
This fan can operate in both pusher and puller configurations by reversing the blades and adjusting the polarity. Its compact depth of just 98 mm makes it perfect for tight installation spaces.
Key Features:
- Airflow: Up to 1050 CFM (1184 m³/hr).
- Brushless Motor: Long-lasting and low maintenance.
- IP68 Protection: Dust and water-resistant design.
- Energy Efficient: Consumes only 132 W of power.
- Compact Dimensions: Suitable for tight installations.
Specifications:
- Airflow: 1184 m³/hr (1050 CFM)
- Diameter:
- Blade: 280 mm (11 inches)
- Housing: 305 mm (12 inches)
- Depth: 98 mm (3.9 inches)
- Weight: 2.2 kg
- Voltage: 12V DC
- Current Draw: 11A
- Power Consumption: 132 W
- Fan Type: Pusher or Puller (reversible blades)
- Motor Type: Brushless
- Protection: IP68 certified
Kit Contents:
- Davies Craig 11-inch Thermatic® Brushless Cooling Fan
- Installation guide
Applications:
- Radiator cooling fan
- Air conditioner condenser fan
- Oil cooler fan
