The Davies Craig 8-inch (20 cm) Thermatic® Cooling Fan (12V) is a compact, reliable fan designed to meet the cooling needs of smaller radiators, air conditioner condensers, and oil coolers.
This versatile fan can operate in both pusher and puller configurations by reversing the blade and polarity. Its small size and low power consumption make it a space-saving and energy-efficient choice for compact setups.
Key Features:
- Airflow: Up to 400 CFM (680 m³/hr).
- Bi-Directional Airflow: Usable in both pusher and puller configurations.
- Energy Efficiency: Reduces fuel consumption while enhancing engine performance.
- Compact Design: Depth of only 56 mm, perfect for tight spaces.
- Motor Options: Available with brushed or long-life brushless motor.
Specifications:
- Airflow: 400 CFM (680 m³/hr)
- Maximum Current Draw: 5A (12V)
- Dimensions:
- Height: 211 mm
- Width: 213 mm
- Depth: 56 mm
- Weight: 0.88 kg
- Operating Voltage: 12V DC
Kit Contents:
- 8-inch Thermatic® Fan (12V)
- Motor, fan blade, shroud, and mounting feet
- Installation guide
Optional Accessories:
- Universal Fan Fitting Kit (#0579 or #0578)
- Thermatic® Fan Switches (available in mechanical and digital versions)
Applications:
- Radiator cooling fan
- Air conditioner condenser fan
- Oil cooler fan
